VL5
Target and Training UAS
Viima VL5 is a fixed-wing UAS platform manufactured with additive manufacturing. Glueless single tool assembly makes assembly and repair fast and easy. VL5 is a perfect starting point for training basic fixed-wing operations, interception testing and R&D platform.
Print. Assemble. Fly
VL5 can be 3D-printed with most commercial FDM 3D-printers. We also offer manufacturing licences, comprehensive manuals, assembly and training videos for quick start.
Max payload: 1,2 kg
Max range: 200 km
MTOW: 3Kg
Max flight time: 200 min
Cruise speed: 60km/h
Launch method: Bungee cord
Video link: Analog 4,9-6,2Ghz VTX with 25mW up to 3W transmit power
Max video range: 20-25Km
Control link: 915Mhz/2,4Ghz or requested custom solution
Firmware: Ardupilot
Packaging dimensions: 20×20×70(cm)
Specification
Train, Test, Repeat
Start manufacturing
Viima offers manufacturing licence, microfactory design services and electronic kits. Contact us if you want to use VL5 at an event or want to know more about manufacturing licence.
